Streaming Client

Live audio and advertisement streaming.

Streaming Client from Barix is the standard streaming solution for professional network audio players, supporting MP3/AAC+ streams from network and M3U playlists, as well as G.711 and PCM raw support.

The deviced are integratable into an existing infrastructure with control over CGI commands and over a local web interface. They can be used for Broadcast, Internet Radio, as well as VoIP applications.

  • Plays MP3/AAC+ streams from network (HTTP, RTP, BRTP) and M3U playlists (HTTP and local)
  • G.711 and PCM raw support in RTP/BRTP
  • Supports authentication (HTTP, Shoutcast, Icecast)
  • Shoutcast meta-data displayed on hardware featuring LCD
  • Autoplay functions plays all audio files inside USB/microSD without playlist (standalone mode)
  • Control and configuration using a standard web browser
  • Monitoring using SNMP and Barimon (HTTP, UDP)
  • Command interface via Serial, TCP, UDP, HTTP (CGI)
  • Priority notification port
  • HTTP proxy support
  • Remote control support via API, IR, VSC (Volume Source Control) panel
  • Serial gateway to transmit RS232 data to a remote location
  • Decoding correction allows fine tuning of the playback speed
  • Shoutcast metadata or commands can trigger the playback of local audio files
  • Automatic update of firmware, configuration and local contents (via HTTP)
  • Exstreamer 205 features a line input for passing audio from an external device (portable MP3 player / smartphone)
  • Relay control (on proper devices)
  • ‘User Interface Development Kit’ to design your own Web look and feel

Devices Available for Streaming Client

Streaming Client Exstreamer 100, 105, 110, 120

IP Audio decoders for broadcast, interner radio and VoIP applications

  • AACplus, MP3, Ogg Vorbis, G.711, PCM Decoding
  • IP Streaming via TCP, UDP, RTP, Multicast
  • Line Level Output (Stereo)
  • RS-232 Serial Port
  • Optional: Relay Output, IR receiver and Display
  • MicroSD or USB Flash Interface

Ordering numbers for Exstreamer 100, 105, 110, 120

  • 2005.9051
    Extreamer 100 EU package
  • 2005.9052
    Extreamer 100 US package
  • 2006.9056
    Extreamer 100 NoPSU package
  • 2006.9057
    Extreamer 100 UK package
  • 2011.9109
    Extreamer 105 EU package
  • 2011.9110
    Extreamer 105 US package
  • 2011.9111
    Extreamer 105 UK package
  • 2007.9079
    Extreamer 110 EU package
  • 2007.9080
    Extreamer 110 US package
  • 2007.9083
    Extreamer 110 UK package
  • 2008.9087
    Extreamer 110 NoPSU package
  • 2010.9100
    Extreamer 120 EU package
  • 2010.9101
    Extreamer 120 US package
  • 2010.9102
    Extreamer 120 UK package
  • 2010.9103
    Extreamer 120 NoSPU package
  • 2006.9072
    Wall Mounting Bracket
  • 2007.9082
    Barix 19″ Rack mount
  • 2006.9054
    Cable Set Audio
  • 2003.9017
    IR Kit (Reciever + Remote)

Streaming Client Exstreamer 200, 205

IP Audio decoders that plays out via a built-in amplifier to 8 Ohm speakers

  • G.711, uLaw, aLaw, PCM Encoding
  • AACplus, MP3, Ogg Vorbis, G.711, PCM Decoding
  • IP Streaming via TCP, UDP, RTP, Multicast
  • Amplified Output 2x25W (8 Ohm)
  • IR interface
  • MicroSD or USB Flash Interface

Ordering numbers for Exstreamer 200, 205

  • 2005.9055
    Exstreamer 200 EU/US package
  • 2011.9113
    Exstreamer 205 EU/US package
  • 2006.9054
    Cable Set Audio
  • 2003.9017
    IR Kit (Receiver + Remote)
  • 2006.9072
    Wall Mounting Bracket
  • 2007.9082
    Barix 19’’ Rack mount

Streaming Client Exstreamer 500

Professional Multiprotocol IP Audio de-/encoder with I/O and balanced audio

  • MP3, G.711, PCM Encoding
  • MP3, G.711, PCM, AACplus, Ogg Vorbis Decoding
  • Shoutcast/Icecast Source capability
  • IP Streaming via TCP, UDP, RTP, Multicast
  • Balanced Line Level Input and Output (Stereo)
  • RS-232 / RS-485 Serial Port
  • 4 Relay Outputs
  • 4 Contact Closure Inputs
  • USB Flash Memory Interface

Ordering numbers for Exstreamer 500

  • 2010.9096
    Exstreamer 500 Intl package

    Device, universal power supply, screw terminal connectors, DB9 to XLR adapter cable.

  • 2007.9082 19’’
    Barix Rack mount

Streaming Client Exstreamer P5

PoE powered IP speaker to make any 8 Ohm speaker IP capable

  • AACplus, MP3, Ogg Vorbis, G.711, PCM Decoding
  • IP Streaming via TCP, UDP, RTP, Multicast
  • Amplified Output 5W (8 Ohm)
  • RS-485 and IR port for local control
  • Powered over Ethernet (PoE)

Ordering numbers for Exstreamer P5

  • 2010.9104
    Exstreamer P5 PoE package

Streaming Client IC Graph

Customized communication interfaces

  • Build user interfaces
  • Easy to configure
  • Java based
  • Free to use

Ordering numbers for IC Graph
