IP Audio Client (IPAC) Firmware

Flexible Firmware for Delivering Critical Messages, featuring Multi-Layer Priority Handler

Barix IP Audio Client (IPAC) firmware is designed for the Fire & Safety, ProAV, IT, and Unified Communications sectors. This firmware enhances critical communications with features like multi-layer priority stream handling for up to five audio sources.

IP Audio Client (IPAC) firmware supports a variety of audio codecs including OPUS, AAC, PCM, MPEG, G.711, and G722, making it effective for paging, emergency notifications, and background music.

IPAC Web API ensures easy customization and third-party system integrations.

It efficiently delivers critical messages out to the public, from mass notifications to VoIP calls, in the most reliable way following the Barix tradition.

IP Audio Client (IPAC) Firmware Preview

Priority Stream Handling:

✓ 5 Layers

Network Audio Input:

✓ HTTP(S)

✓ RTP

✓ Local Files (UDP / REST API playback trigger)

✓ Local Scheduler

✓ USB audio

✓ Dante (only licensed PNs)

✓ SIP

✓ InformaCast / SynApps

Analog Audio Input:

✓ 1x Mic (2.1V)/Line input only with Annuncicom MPI400

✓ 1x Phantom Mic (18V) input only with Annuncicom MPI400

Audio Output:

✓ Analog

✓ RTP Forwarding

✓ Dante Forwarding (only Licensed PN’s)

Audio Codecs:

✓ OPUS

✓ PCM

✓ MPEG

✓ AAC

✓ G.711, G.722

AES67:

✓ AES67 decoder stand alone mode

Intercom Paging Client:

✓ IC paging

✓ Simple Paging

✓ InformaCast (only Licensed PNs)

✓ SynApps

Dante (Licensed PN required) 3 modes:

✓ Dante as a source: to play a Dante stream to the analog output (IPAC as RX)

✓ Dante Forwarding: to play the main audio output into a Dante system (IPAC as TX)

✓ Dante as input to feed the SIP client (IPAC as RX to feed SIP Client)

REST API:

✓ Publicly available to control the device remotely

Devices Available for IP Audio Client (IPAC) Firmware

IP Audio Client (IPAC) Firmware Exstreamer M400

New Architecuture Multiformat IP Audio Decoder

  • Turns PA into extensive Audio over IP systems
  • Wide variety of audio environements supported
  • Singlewire Certified – requires extra license
  • Syn-Apps Revolution Certified
  • Codecs include PCM, AACplus, MP3, OPUS, G.711, G.722

Ordering numbers for Exstreamer M400

Exstreamer M400

2021.9291  Exstreamer M400 EU (incl. Syn-Apps)

2020.9292  Exstreamer M400 US (incl. Syn-Apps)

2020.9293  Exstreamer M400 UK (incl. Syn-Apps)

2020.9294  Exstreamer M400 NoPSU (incl. Syn-Apps)



Exstreamer M400 Informacast

2020.9295  Exstreamer M400 InformaCast EU

2020.9296  Exstreamer M400 InformaCast US

2020.9297  Exstreamer M400 InformaCast UK

2020.9298  Exstreamer M400 InformaCast NoPSU

2019.3160  InformaCast License (must be ordered with device)



Exstreamer M400 Dante® – Including Dante® license

2023.9403P  Exstreamer M400 EU Dante®

2023.9404P Exstreamer M400 US Dante®

2023.9405P  Exstreamer M400 UK Dante®

2023.9406P  Exstreamer M400 Dante® NoPSU



Exstreamer M400 Dante® + InformaCast –  Including Dante® license + Singlewire’s InformaCast license

2023.9407P  Exstreamer M400 EU Dante® + InformaCast

2023.9408P Exstreamer M400 US Dante® + InformaCast

2023.9409P  Exstreamer M400 UK Dante® + InformaCast

2023.9410P  Exstreamer M400 Dante® + InformaCast NoPSU

IP Audio Client (IPAC) Firmware Exstreamer MR400

Ordering numbers for Exstreamer MR400

Exstreamer MR400 (Made in Europe)

Exstreamer MR400

2023 9418P Exstreamer MR400 Package
2023 9431P Exstreamer MR400 InformaCast
2023 9432P Exstreamer MR400 Dante®
2023 9433P Exstreamer MR400 Dante® + InformaCast

IP Audio Client (IPAC) Firmware IP Former TPA400 - Plenum Rated per UL Standard 2043

Adds advanced IP encoding / decoding functions to any loud-speaker.

  • VOIP/SIP capabilities
  • Plenum Rated per UL Standard 2043
  • Audio output with up to 5 Watt (This is suitable for most corporate environments. Need more power? Checkout the Exstreamer MPA400 with up to 40W power delivery)
  • POE Powered
  • Built-in amplifier over temperature protection
  • IP Streaming via TCP, UDP, RTP, Multicast
  • Secured HTTPS connection
  • Compatible with any speaker
  • Singlewire Certified – requires extra license
  • Syn-Apps Certified

Ordering numbers for IP Former TPA400 – Plenum Rated per UL Standard 2043

IP Former TPA400

2020.9299P – IP Former TPA400 (incl. Syn-Apps)

2020.9314P – RetailPlayer TPA400 PoE Package (incl. free SaaS Portal)



IP Former TPA400 Informacast

2020.9301P – IP Former TPA400 InformaCast

2019.3160 – InformaCast License (must be ordered with device)



IP Former TPA400 Dante®  – Including Dante® license

2023.9401P – IP Former TPA400 Dante® – Including Dante® license



IP Former TPA400 Dante® + InformaCast –  Including Dante® license + Singlewire’s InformaCast license

2023.9402P – IP Former TPA400 Dante® + Singlewire’s InformaCast – Including Dante® license + Singlewire’s InformaCast license

IP Audio Client (IPAC) Firmware Exstreamer MPA400

IP Audio Decoder and Amplifier

  • Up to 40W RMS @ 4Ohm Speaker Output
  • IEEE 802.3af / 802.3at / 802.3bt type 1 and type 2 or external Power Supply 24VDC, 50W max.
  • Automatic Amplifier Setting according to input voltage and impedance detected
  • Singlewire Certified – requires extra license
  • Syn-Apps Revolution Certified
  • Multi-layer source priority management
  • SIP Client with SIPS, SRTP support
  • REST API to interface with 3rd party apps

Ordering numbers for Exstreamer MPA400

Exstreamer MPA400 (made in Europe)

2020.9317P Exstreamer MPA400 PoE Package



Exstreamer MPA400 Singlewire’s Informacast license (made in Europe)

2020.9325P Exstreamer MPA400 Informacast Package

2019.3160 InformaCast License (must be ordered with device)



Exstreamer MPA400 Dante® (made in Europe) – Including Dante® license

2023.9411P Exstreamer MPA400 Dante®



Exstreamer MPA400 Dante® (made in Europe) + InformaCast – Including Dante® license + Singlewire’s InformaCast license

2023.9412P Exstreamer MPA400 Dante® + InformaCast



Accessories

2022.2114P Power Supply Exstreamer MPA400(24V_3.5A)*Optional

2006.9072 Wall mount bracket Measure: 116/30/29mm *Optional

2007.9082 19” Rack mount shelf – for up to 4 devices

IP Audio Client (IPAC) Firmware Annuncicom MPI400

Intercom / Paging device with contact closure inputs, relay outputs, Line and Mic / Speaker support

  • Paging / Intercom device with talkback for classrooms or factory buildings
  • Door Intercom station
  • Paging / Intercom endpoint for public transportation

Ordering numbers for Annuncicom MPI400

Annuncicom MPI400 (Made in Europe)

2021.9330P MPI400 PoE Package

Annuncicom MPI400 Singlewire’s Informacast license

2022.9372P InformaCast Package (must be ordered with InformaCast License)

2019.3160 InformaCast License (must be ordered with device)

Annuncicom MPI400 Dante®

2023.9413P Annuncicom MPI400 Dante® – Including Dante® license

Annuncicom MPI400 Dante® + InformaCast – Including Dante® license + Singlewire’s InformaCast license

2023.9414P Annuncicom MPI400 Dante® + InformaCast

Accessories

2011.5032 Accessories Power supply 24VDC

2006.9072 Accessories Wall mount bracket

2007.9082 Accessories 19“ Rack mount
