Instreamers

IP encoders with line level analog input (stereo), integrated Icecast server and more

The Instreamer makes the streaming of audio over IP networks smooth and easy. It encodes any incoming audio signal into a high-quality stream and can send the stream to up to 32 different destinations across the LAN or over the internet.

Instreamers support unicast, broadcast or multicast streaming along with peer-to-peer connections with other Barix devices.

It can also be used for integration into wide audio infrastructures with Shoutcast, Icecast or an other third party software. Simple web and command interfaces make the firmware configurable and the audio stream can be adjusted to the network bandwidth.

An easy-to-install and cost-effective solution for professional audio streaming.

  • Creates streams into any system
  • Works perfectly together with Barix Exstreamers
  • Also suitable for MoH applications

How can you Implement this Solution in a Wider System

Devices Available for Instreamers

Instreamers Annuncicom 100

Intercom / Paging codec with contact closure inputs and relay output

  • MP3, G.711, G.722, PCM
  • Shoutcast/Icecast Source capability
  • Mic/speaker connection
  • Amplified Output 2W (8 Ohm)
  • Contact closure inputs, Relay output

Ordering numbers for Annuncicom 100

  • 2006.9062
    Annuncicom 100 EU package
  • 2006.9063
    Annuncicom 100 US package
  • 2006.9064
    Annuncicom 100 NoPSU package
  • 2006.9065
    Annuncicom 100 UK package
  • 2011.5032
    Accessories Power supply 24VDC
  • 2006.9072
    Accessories Wall mount bracket
  • 2007.9082
    Accessories 19“ Rack mount
  • 2006.9054
    Accessories Cable Set Audio

Instreamers Annuncicom 200

Intercom / Paging codec with 8W amplifier

  • MP3, G.711, G.722, PCM
  • Shoutcast/Icecast Source capability
  • Mic/speaker and line level interfaces
  • Amplified output 8W (8 Ohm)
  • Contact closure inputs, relay output
  • Aiphone Door Station Interface (IE/JE series)

Ordering numbers for Annuncicom 200

  • 2008.9090
    Annuncicom 200 PoE package
  • 2011.5032
    Accessories Power supply 24VDC
  • 2006.9072
    Accessories Wall mount bracket
  • 2007.9082
    Accessories 19“ Rack mount
  • 2006.9054
    Accessories Cable Set Audio

Instreamers Instreamer Classic

Encoder for analog audio sources in real time with TCP, UDP, Shoutcast, Multicast RTP stream

  • MP3, G.711, G.722, PCM Encoding
  • IP Streaming via TCP, UDP, RTP, Multicast
  • Shoutcast/Icecast Source capability
  • Audio Level Supervision with SNMP Trap generation
  • Line Level Input (Stereo)

Ordering numbers for Instreamer Classic

  • 2012.9121
    Instreamer EU Package
  • 2012.9123
    Instreamer US Package
  • 2012.9124
    Instreamer UK Package
  • 2012.9125
    Instreamer noPSU Package

Instreamers Instreamer ICE

Encoder with a built-in Icecast server for an immediate web radio stream

  • MP3 and AAC+ encoding
  • Stream Authentication
  • Icecast source mode
  • Stream Relay (stream forwarding)
  • Streams to Icecast internet radio service
  • Integrated Icecast streams to 100 simultaneous listeners without radio service
  • Line level input (stereo)

Ordering numbers for Instreamer ICE

  • 2018.9237
    Instreamer ICE EU Package
  • 2018.9238
    Instreamer ICE US Package
  • 2018.9239
    Instreamer ICE UK Package
  • 2018.9240
    Instreamer ICE NoPSU Package
