Instreamers

IP encoders with line level analog input (stereo), integrated Icecast server and more.

The Instreamer makes the streaming of audio over IP networks smooth and easy. It encodes any incoming audio signal into a high-quality stream and can send the stream to up to 32 different destinations across the LAN or over the internet. Instreamers support unicast, broadcast or multicast streaming along with peer-to-peer connections with other Barix devices. It can also be used for integration into wide audio infrastructures with Shoutcast, Icecast or other third party software. Simple web and command interfaces make the firmware configurable and the audio stream can be adjusted to the network bandwidth. An easy-to-install and cost-effective solution for professional audio streaming.

Devices Available for Instreamers

Instreamers Annuncicom 100

Intercom / Paging codec with contact closure inputs and relay output

  • MP3, G.711, G.722, PCM
  • Shoutcast/Icecast Source capability
  • Mic/speaker connection
  • Amplified Output 2W (8 Ohm)
  • Contact closure inputs, Relay output

  Detailed product sheet

Get in contact

Ordering numbers for Annuncicom 100

2006.9062 Annuncicom 100 EU package

2006.9063 Annuncicom 100 US package

2006.9064 Annuncicom 100 NoPSU package

2006.9065P Annuncicom 100 UK package

2011.5032 Accessories Power supply 24VDC

2006.9072 Accessories Wall mount bracket

2007.9082 Accessories 19“ Rack mount

2006.9054 Accessories Cable Set Audio

Instreamers Annuncicom 200

Intercom / Paging codec with 8W amplifier

  • MP3, G.711, G.722, PCM
  • Shoutcast/Icecast Source capability
  • Mic/speaker and line level interfaces
  • Amplified output 8W (8 Ohm)
  • Contact closure inputs, relay output
  • Aiphone Door Station Interface (IE/JE series)

  Detailed product sheet

Get in contact

Ordering numbers for Annuncicom 200

2008.9090 Annuncicom 200 PoE package

2011.5032 Accessories Power supply 24VDC

2006.9072 Accessories Wall mount bracket

2007.9082 Accessories 19“ Rack mount

2006.9054 Accessories Cable Set Audio

Instreamers Instreamer Classic

Encoder for analog audio sources in real time with TCP, UDP, Shoutcast, Multicast RTP stream

  • MP3, G.711, G.722, PCM Encoding
  • IP Streaming via TCP, UDP, RTP, Multicast
  • Shoutcast/Icecast Source capability
  • Audio Level Supervision with SNMP Trap generation
  • Line Level Input (Stereo)

  Detailed product sheet

Get in contact

Ordering numbers for Instreamer Classic

2012.9121 Instreamer EU Package

2012.9123 Instreamer US Package

2012.9124 Instreamer UK Package

2012.9125 Instreamer noPSU Package

Instreamers Instreamer ICE

Encoder with a built-in Icecast server for an immediate web radio stream

  • MP3 and AAC+ encoding
  • Stream Authentication
  • Icecast source mode
  • Stream Relay (stream forwarding)
  • Streams to Icecast internet radio service
  • Integrated Icecast streams to 100 simultaneous listeners without radio service
  • Line level input (stereo)

  Detailed product sheet

Get in contact

Ordering numbers for Instreamer ICE

2018.9237P Instreamer ICE EU Package

2018.9238 Instreamer ICE US Package

2018.9239 Instreamer ICE UK Package

2018.9240 Instreamer ICE NoPSU Package

Instreamers Multicoder M400

Low-latency Audio over IP Encoder that can do AAC+ and OPUS with latest Security

  • OPUS, AAC+, MP3, PCM and G.711 codec
  • 4 encoding engines (up to 10 targets per engine)
  • RTP and BRTP streaming protocol
  • Line level input (mono, stereo)
  • Supply voltage 5VDC

  Detailed product sheet

Get in contact

Ordering numbers for Multicoder M400

2023.9434P Multicoder M400 EU Package

2023.9435P Multicoder M400 US Package

2023.9436P Multicoder M400 UK Package

2023.9437P Multicoder M400 NoPSU Package

Keep me updated about Instreamers
